D-Max

Welcome to a whole new era in pick-up trucks. The all-new ISUZU D-MAX – toughness, redefined. Encompassing aggressive new styling and new levels of safety – plus ISUZU’s legendary durability and fuel efficiency – the all-new ISUZU D-MAX strives ahead of its competition.


With an all-new plush interior that rival most saloon cars, you may soon forget that you're driving a pick-up truck.


Whether it’s hauling big loads, powering through the work week, cruising through the weekend or going where the others won’t, this is one pickup you can depend on. Put it to the test. You won’t be disappointed.






CALL US NOW ! 085 - 663 355 (MIRI) or 086-318668 (BINTULU)

Specifications

  ISUZU D-MAX
2.5L 4x2 MT
ISUZU D-MAX
2.5L 4x2 MT HI-RIDE
ISUZU D-MAX
2.5L 4x4 MT-L
ISUZU D-MAX
2.5L 4x4 MT
ISUZU D-MAX
2.5L 4x4 AT
ENGINE
Model 4JA1-L 4JK1-TCX
Type In-Line 4-Cylinder Turbo Diesel In-Line 4-Cylinder VGS Turbo Intercooler Diesel DOHC 16V
Displacement (cc) 2,499
Bore x Stroke (mm) 93.0 x 92.0 95.4 x 87.4
Compression Ratio 18.5:1 18.1:1
Maximum Output (kW (PS) @ rpm) [ISO NET] 58 (79) @ 3,900 100 (136) @ 3,600
Maximum Torque (Nm (kgm) @ rpm) [ ISO NET] 176 (18.0) @ 1,800 320 (32.6) @ 1,800 - 2,800
Fuel System Direct Injection Mechanical High Pressure Injection Pump Direct Injection Electronic Commonrail
TRANSMISSION
Type   5-Speed Manual 5-Speed Manual 5-Speed Manual 5-Speed Manual 5-Speed Automatic
Gear Ratio 1st 4.008 4.008 4.008 4.008 3.520
  2nd 2.301 2.301 2.301 2.301 2.042
  3rd 1.427 1.427 1.427 1.427 1.400
  4th 1.000 1.000 1.000 1.000 1.000
  5th 0.828 0.745 0.745 0.745 0.716
  Reverse 3.651 3.651 3.651 3.651 3.224
  Final 4.300 4.100 4.100 4.100 3.909
SUSPENSION & BRAKES
Suspension Front Independent Double Wishbones with Coil Springs & Stabilizer
  Rear Semi-Elliptical Leaf Springs
Shock Absorber All Wheels Hydraulic Double Action Telescopic
Brakes Front Ventilated Disc with 2-Pot Calipers
  Rear Leading & Trailing Drums
STEERING
Steering System Rack & Pinion Power Steering System
Min. Turning Radius (m) 6.1 6.3
Tyres 195R15 245/70R16 255/65R17
Wheels 15” Steel 16” Alloy 17” Alloy
CAPACITIES
Seating Capacity 5-Person
Fuel Tank Capacity (L) 76
EXTERIOR
Headlamps Multi-Reflector Halogen PROJECTOR Ellipsoid System
Front Fog Lamps - Built-In
Engine Hood Garnish Grey Chrome
Door Outer Mirror Black Colour Finished with Manual Mirror Control Chrome Finished Electric Folding & Control with LED Intergrated Turn Signal
Door & Tailgate Handles Black Colour Chrome
Roof Rail - Equipped
Rear Combination Lamp Standard LED
Rear Bumper One Step Type with Black Colour Finished One Step Type with Chrome Plating Finished
INTERIOR FEATURES
Meter Panel Standard with Information Display e-LUMAX with Advance Multi-Information Display
Steering 3-Spoke Urethane 3-Spoke Leather Wrapped 3-Spoke Urethane 3-Spoke Leather Wrapped with Audio & Hands-Free Switches
Audio System 1-Din AM/FM USB with 2-Speakers ISUZU 1-Din AM/FM MP3 WMA Player with 4-Speakers & 2-Tweeters [ISUZU Premium Audio System]
Built-In 2-Din AM/FM MP3 WMA Player
USB & Bluetooth with Exciter, Speakers & Tweeters
Assist Grip - Fixed Assist Grips for Driver & Front Passenger
Power Door Lock Electric Control Electric Control with Speed Sensing Automatic Door Lock
Seats Tricot Fabric Jacquard Flat Woven with Tricot Trim Bolster
Door Windows Electric Control Electric Control with Auto-Up & Down and Jam Protection for Driver
Middle Console Box Arm Rest Compartment Arm Rest Compartment with Rear Cups Holder
Map Lamp Dual for Driver & Front Passenger with Cards Clipper Dual for Driver & Front Passenger with Overhead Console
Cabin Lamp Equipped
Ash Tray Cup Type
Power Outlet - Inside Top Tier Glove Box
Cigarette Lighter Equipped
SAFETY FEATURES
SRS Airbags (DUAL) - Driver & Front Passenger
ABS with EBD - Equipped
Brake Assist (BA) - Equipped
Electronic Stability Control (ESC) - Equipped
Traction Control System (TCS) - Equipped
Load Sensing Proportional Valve (LSPV) Equipped -
Limited Slip Differential (LSD) - Equipped -
Body Construction Cabin Construction with Tailor Blank Welded High Tensile Steel
Side Door Impact Beams Equipped
Collapsible Steering Column Equipped
Windscreen Front Laminated with Rear Defogger
Wiper with Speed Intermittent with Variable Intermittent
Seat Belts 3-Point ELR for All Occupants 3-Point ELR for All Occupants plus Pre-Tensioner with Load Limiter for Front Seats
Child Seat Anchorage ISO FIX with Top Tether for Rear Seats
Vehicle Security System Anti-Theft Alarm System with Immobilize Anti-Theft Alarm System with Key-Coded Immobilizer
Child Protector Safety Lock Equipped
High Mount Stop Lamp Equipped
ACCESSORIES
Roll Bar - Optional
Bed Liner/ Bed Rubber Mat Optional Equipped
Side Step Optional Equipped
